5MP 30X Zoom WIFI PTZ IP Camera iCsee Outdoor Speed Dome Camera colorful night vision cloud storage ip camera ip66 waterproof
Features :
v Supporting human detection, face detection, and support to customize other intelligent functions
v 1/2.7"5MP reolution,low illumination clear and fine images;
v HD resolution 2592*1944;
v Support for wifi and wire connections;
v Support 2D/3D noise reduction,digital wide dynamic;
v Advanced H.265 AI video compression,Super low rate,high definition quality of image;
v Professional anti-lightning,conform to GB/T17626.5 and IEC61000-4-5.
v Support mobile phone monitoring(iOS, Android);
v Provide web,CMS,provide SDK development;
v Support cloud technology,easy to achieve network penetration,fro in-line and alarm
v information pushed.
v TF Card:Max to 128GB.
v P2P APP:iCsee, XMeye.
v PC Software: CMS.
v 30X Zoom Auto Focus Lens(4.7-94mm 20X Optical+10X Digital).
v 4pcs Array Infrared LEDs. 80m IR Night Vision.
v 4pcs white leds,60m white light distance.
v Colorful night vision mode.
v Built-in Microphone&Speaker,Support Two Way Audio Talk Back.
v Support TF/Micro SD card, up to 128G(Don't included TF Card).
v Pan tilt rotation, horizontal:355° & vertical:90°.
v Support Cruise Zoom Tracking.Support 8 cruise lines, up to 128 preset points cruise,zoom lens status can be saved during the preset .
v Metal Housing Material,Outdoor Use,Waterproof IP66.
Technical Specifications:
|
Camera Module |
|
|
System structure |
Embedded RTOS, dual-core 32-bit DSP (XM550AI),pure hard compression |
|
Sensor |
5.0M 1/2.7"SC5335P low illumination CMOS sensor ,color 0.001Lux F1.2,black/white 0.0001Lux F1.2 |
|
Shutter Speed |
1/50(1/60)s to 1/10,000s |
|
Image output |
Wire connection Main stream: 2592*1944 15fps; sub-stream: 640*360 25fps; wifi connection Main stream: 2592*1944 12fps; sub-stream: 640*360 12fps, |
|
Day and night |
Support IR-CUT |
|
Noise reduction |
Support 2D/3D |
|
Wide dynamic |
Support digital Wide dynamic |
|
Lens |
|
|
Focal length |
F=4.7-94mm lens, 20X optical zoom+10X Digital Zoom |
|
Zoom Speed |
Approx 4s |
|
Angel of view |
58.9°(wide)~2.1°(tele) |
|
Max.Aperture |
F1.6-F3.5 |
|
PTZ |
|
|
Pan Range |
355° |
|
Pan speed |
Cnfigurable,from 6– 40°/s,preset speed:40°/s |
|
Tilt Range
|
0-90° |
|
Tilt Speed |
Configurable,from 6– 30°/s,preset speed:30°/s |
|
Proporational Zoom |
Yes |
|
Preset |
128 |
|
Cruise |
8 cruises lines,up to 16 presets for each cruise line |
|
Power off memory |
yes |
|
Action mode |
Preset/Cruise/Track/Auto Scan/Random Scan |
|
Video |
|
|
Max.Resolution |
2592*1944 |
|
Main Stream |
Wire connection:2592*1944 15fps,wifi connection 2592*1944 12fps |
|
Sub Stream |
Wire connection: 640*360 25fps;wifi connection : 640*360 12fps |
|
Video compression |
H.265X coding,support dual stream,AVI;0.1M~10Mpbs variable |
|
SVC |
yes |
|
Audio |
|
|
Audio compression |
G.711,support bidrectional talk,audio&video synchronization |
|
Audio interface |
1ch input,level:2Vp-p,impedance:1kΩ,support sound pick-up input;1ch output,impedance:16Ω,30mw,support microphone |
|
Smart Features |
|
|
Intelligence analysis |
Supporting human detection, face detection, and support to customize other intelligent functions. |
|
Network |
|
|
Network Support |
2.4 GHz to 2.4835 GHz/IEEE802.11b. 802.11g. 802.11n Draft |
|
Security Measures |
Authenticated username and password, MAC address binding, HTTPS encryption, 802.1X authenticated access, IP address filter |
|
Client |
CMS |
|
Web Browser |
IE 10+, Chrome 57+, Firefox 52+, Safari 12+ |
|
ONVIF |
Yes |
|
Interface |
|
|
Communication Interface |
1*RJ45 10/100M adaptive Ethernet port; support RTSP/FTPDHCP/NTP/UPnP etc |
|
POE |
Yes |
|
Supplement Light |
|
|
IR Distance |
80m |
|
Smart IR |
yes |
|
General |
|
|
Power |
DC12V |
|
Operating Conditions |
Temperature: -40°C to 70°C (-40°F to 158°F), Humidity: ≤ 95% |
|
Size(mm) |
239*137*215 |
|
Weight(kg) |
1.5KG |
|
Package Size(mm) |
250*150*300 |
|
Package Weight(kg) |
2.5KG |
|
Web Client Language |
12 languages: Simplified Chinese,traditional Chinese,English, Russian,German,Italian,French,,Portuguese, Spanish, Korean, Portuguese (Brazil),Czech |
|
Approval |
|
|
Protection |
Lightning Protection, Surge Protection and Voltage Transient Protection, ±6kV Line to Gnd, ±3kV Line to Line, IEC61000-4-5, IP66 Standard |
Q:
1.Does this camera support NVR?
A: Yes,the wifi camera can use NVR via RJ45 port.any NVR has the onvif protocol is ok, We strongly recommend using XM orginal NVR,all functions of the camera can be realized.
Q: Does it support face recognition?
A: Yes, this camera has face recognition,but only works when you use it with XM orginal AI NVR.
Q: Does it has cloud storage function?
A:Yes, this camera has cloud storage function, you can see the function in app iCsee.
Q: Does it support automatic cruise?
A:Yes, this camera automatic cruise function, you can see how to use this function by reading user manual.
